10A PWM Motor Speed Control Switch Manual (12Vdc to 40Vdc)

Features:
1.This is a simple and easy-to-use DC motor speed controller of stable performance.
2.Speed controller is made with high quality circuit board which ensures a longer service life.
3.Equipped with fuse tube to protect the speed controller from burning out that short circuit causes.
4.With reverse connection protection function.
5.Designed with convenient screw terminals for quick wiring.

Specification:
Input Voltage: DC 12V-40V
Control Power: 0.01-400W
Rated Current: 8A
Maximum Current: 10A
Static Current: 0.02A(standby status)
Frequency: 13kHz
Speed Adjustment Range: 10%-100%
Hole Diameter: 3.2mm
Operating Temperature: -20~125
Dimensions: 75*60*28mm / 2.95*2.36*1.10in
Package Weight: Approx. 73g/2.6oz
