TPM-10 Digital Thermometer is a digital temperature measuring module with a resistive sensing design. It measures temperature in Celsius and provides a clear digital reading for everyday monitoring. The unit supports a wide measurement range and a fine 0.1-degree resolution. It is powered by two LR44/AG13 coin batteries and uses a 1.5V supply. The compact body and display dimensions make it suitable for panel-style mounting.
Features of TPM-10 Digital Thermometer
- Digital temperature measurement
- Resistive sensor design
- 0.1°C resolution
- Celsius-only operation
- Coin battery power
Specifications of TPM-10 Digital Thermometer
- Model: TPM 10
- Temperature range: -50 ~ +110 °C
- Resolution: ± 0.1 °C
- Accuracy: ± 1
- Unit: Celsius only
- Voltage: 1.5 V
- Battery type and quantity: 2 LR44/AG13 coin batteries
- Overall dimensions: 48x28x5 mm
- Mounting hole spacing: 46.2×26.7 mm
- Display size: 36×16 mm
How to Use TPM-10 Digital Thermometer
- Install two LR44/AG13 coin batteries.
- Mount the unit using the specified hole spacing.
- Read the temperature value from the display.
More Info
- Battery may be missing or empty on arrival.
- Compatible battery type: LR44.
